CS6080-SR Black Cordless (with Lanyard) KIT: CS6080-SR40004VZWW Scanner, LNYD-000060W-04 Lanyard, Non-MFi. Charging Components Sold Separately.
The ultra-versatile CS60 Series Companion Scanner adapts to any workflow. Its groundbreaking design easily converts between corded and cordless operation, handheld and hands-free, as your needs change. As a cordless companion scanner paired to a cradle or mobile device, the CS60 is small enough to tuck in a pocket and offers the latest mobile technology including contactless charging, 18 hours of battery power, a dedicated battery gauge and versatile charging options. As a corded scanner, the CS60 offers compact handheld or hands-free scanning at the checkout counter, self-service kiosk and more. Whether you purchase a corded or cordless model up front, you can change modes at any time for superior investment protection. Simply swap the battery and corded USB converter and the CS60 is ready for a new workflow. A high-resolution megapixel sensor and Zebra’s exclusive PRZM Intelligent Imaging technology provide unparalleled performance on even the most challenging barcodes. A second programmable button lets users seamlessly toggle between two host applications. It’s easy to clean the CS60 shift after shift thanks to best-in-class IP65 sealing and a seamless, crevice-free construction. And Zebra’s unrivaled tools make staging and everyday management easier than ever.
Charging Components Sold Separately
- Technical Information
- Connectivity Technology
- Wireless
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
- 1D:
- Base 32 (Italian Pharma)
- Codabar/NW7
- Code 11
- Code 39
- Code 93
- Code 128
- GS1 DataBar
- I 2 of 5
- Korean 3 of 5
- MSI Plessey
- UPC/EAN
- Aztec
- Composite codes
- Datamatrix
- Dotted datamatrix
- Dotcode
- Han xin
- Maxicode
- Pdf417
- Micro pdf417
- Postal codes
- Qr code
- Micro qr
- Tlc-39
- Securpharm
- OCR-A
- OCR-B
- MICR
- US Currency
- Depth of Field
Designed to withstand multiple drops at 6.0 ft./1.8 m to concrete
- Scanner Range
- Standard Range
- Field of View (Horizontal)
- 45°
- Field of View (Vertical)
- 34°
- Reading Angle (Skew)
- 60°
- Reading Angle (Pitch)
- 60°
- Reading Angle (Roll)
- 360°
- Motion Tolerance
- 508 mm/s
- Maximum Ambient Light
- 108000 lux
- Minimum Print Contrast
- 20%
- Minimum Element Resolution (Code 39)
- 0.13 mm
- Maximum Element Resolution (Code 39)
- 0.51 mm
- Maximum Element Resolution (DataMatrix)
- 0.25 mm
- Maximum Element Resolution (PDF417)
- 0.17 mm
- Illumination Type
- LED
- Illumination Color
- White
- Network & Communication
- Bluetooth
- Yes
- Radio Frequency
- Yes
- Power Description
- Power Supply Included
- Yes
- Input Current
- 400 mA
- Standby Current
- 90 mA
- Battery Information
- Battery Chemistry
- Lithium Polymer (Li-Polymer)
- Battery Capacity
- 745 mAh
- Maximum Battery Run Time
- 18 Hour
- Maximum Battery Recharge Time
- 6 Hour
- Environmental Conditions
- Operating Temperature
- 0°C to 50°C
- Storage Temperature
- -40°C to 70°C
- Humidity (Non-condensing)
- 5% to 95%
- Physical Characteristics
- Form Factor
- Handheld
- Color Family
- Black
- Product Color
- Midnight Black
- Height
- 22.9 mm
- Width
- 45.7 mm
- Depth
- 109.2 mm
- Weight (Approximate)
- 82.2 g
- Miscellaneous
- Ingress Protection (IP) Rating
- IP65
- Application/Usage
- Retail
- Hospitality
- Transportation
- Logistics
- Light/Clean Manufacturing
- Asset Tracking
- Route Accounting
- Inventory
- Merchandising
- Ticketing
